Mespack H-100 Sachet Packaging Machine

Features

For sale: Mespack H-100 automatic sachet packaging machine, designed for packaging powders, granules, liquids and pastes in flat, heat-sealed sachets.

The machine operates from a roll of heat-sealable packaging material. It forms the sachets in an intermittent cycle, doses the product, creates the seals and cuts off the finished packages.

Depending on the product being packed, the machine can work with a suitable dosing system: an auger filler for powders, a volumetric dosing system for granules, or a liquid and paste dosing unit using a pump or piston.

The machine is designed to produce flat sachets with three or four seals.

Technical Data

• Manufacturer: Mespack

• Model: H-100

• Serial number: 100.010

• Delivery date according to documentation: 15 October 2005

• Machine type: Automatic horizontal sachet packaging machine

• Minimum sachet dimensions: 30 × 30 mm

• Maximum sachet dimensions: 100 × 130 mm

• Maximum dosing volume: 1–50 cm³, according to the H-100-S model specifications

• Maximum output: Up to 100 sachets/min, according to the H-100-S model specifications

• Number of dosing stations: 4, according to the H-100-S model specifications

• Maximum packaging film roll diameter: 450 mm

• Film roll core diameter: 70–75 mm

• Electrical power consumption: 7 kW, according to the H-100-S model specifications

• Weight: 500 kg, according to the H-100-S model specifications

Functions and Equipment Described in the Documentation

• Packaging film roll unwinder.

• Film guiding and feed control system.

• Sachet opening system for product filling.

• Photocell for detecting printed registration marks on the packaging film.

• Heat-sealing jaws.

• Cutting system for separating finished sachets.

• Product dosing system selected according to the type of material being packed.

• Safety devices described in the operating manual.

Application

The Mespack H-100 is designed for automatic packaging of products into single-portion sachets. According to the documentation, it can handle powders, granules, liquids and pastes, provided that an appropriate dosing system is installed.

Potential applications include the food, cosmetics and chemical industries, as well as other production environments requiring portioned products in sachet packaging.

Documentation

The machine is supplied with an operating manual covering installation, format adjustment, operation, maintenance and spare parts. The documentation also includes an EC Declaration of Conformity.

Note: The output capacity, dosing volume and number of dosing stations listed above are taken from the H-100-S model specifications included in the manual. The configuration of the specific machine, the installed dosing system and its current technical condition should be confirmed before purchase.
